TECHNICAL DETAILS
HEIGHT 1410 mm.
LENGTH 600 mm.
WIDTH 1740 mm.
TURNS N' OF THE COILING SPINDLE FROM 0 TO 1800 (adjustable)
ADJUSTABLE SPIRAL STEP FROM 0 A 6 mm./turn
CORE SECTION FROM Ø 0,30 TO 5 mm.
COILING WIRES FROM Ø 0,10 TO 0,30 mm.
POWER 2,6 kW FEEDING 220 V.
WEIGHT Kg. 260 WEIGHT WITH PACKING: 395 K
The machine is projected to make small spirals by winding the wire or small plate around a flexible or rigid core in a rectangular or round shape. It is possible to coil with 1 or 2 wires or small plates. The movement is obtained by two motors electronically connected in order to adjust the coiling speed and at the same time adjust the coiling step to realize the spirals with step and attached spirals. The machine has an hammering head, over the coiling part of the m a- chine. The hammering head is controlled by an independent m o tor to obtain the compactness and the shaping of the final product. It is possible to have the hammering working phase indepen dently from the coiling operations. The machine has an external motorized and adjustable coiling group, independent from the other working process..
